The Schmersal Safety Fieldbox enables simple, decentralized connection of up to eight Schmersal safety devices such as sensors, interlocks, light curtains, or E-Stop buttons via pre-assembled 8-pin M12 connectors.
It reduces cabling effort and errors seamlessly communicates via Safety over EtherCAT with the ctrlX SAFETY controller or any ctrlX OS device with Safety PLC app.
Decentralized connection of safety switching devices with the Safety Fieldbox
In modern production facilities, numerous safety switching devices such as sensors, interlocks, light curtains, or emergency stop buttons must be reliably connected and monitored. Conventional cabling solutions are often complex, inflexible, and prone to errors. The Safety Fieldbox enables the decentralized and simple connection of up to eight (Schmersal) safety switching devices via pre-assembled 8-pin M12 connector.
Advantages
- Simple and fail-safe installation
- Easy integration into the control environment
- Cost-effective machine wiring (plug & play)
- Power supply via M12 power connector
- Robust design (IP67)
- Communication via Safety-over-EtherCAT (FSoE) with the ctrlX SAFETY controller or Safety PLC App for ctrlX OS
Target Groups
- Machine Builder
- System Integrator
Topology
SAFETY FIELDBOX - enables the decentralized and simple connection of up to eight (Schmersal) safety switching devices via pre-assembled 8-pin M12 connectors.
INTEGRATION - ctrlX SAFETY controller or any ctrlX OS device with Safety PLC App can be Safety-over-EtherCAT (FSoE) Master for Safety Fieldbox.
